รายละเอียดสินค้า
| Type | Pressure (MPa) | One Stroke Oil (mL) | Full Tank Oil (L) | Available Oil (L) | Handle Force (N) | Size (mm) | Oil Interface | Gauge Interface | Weight (kg) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Low | High | Low | High | A | B | C | |||||||
| P392 | 2.5 | 70 | 32 | 2.5 | 1.67 | 1.44 | 300 | 590 | 120 | 160 | 3/8" NPT | 1/4" NPT | 6.3 |
| P80 | 2.5 | 70 | 32 | 2.5 | 2.25 | 1.98 | 300 | 590 | 120 | 170 | 3/8" NPT | 1/4" NPT | 8 |
| P160 | 2.5 | 70 | 32 | 2.5 | 3.58 | 3.24 | 300 | 590 | 140 | 180 | 3/8" NPT | 1/4" NPT | 10 |
| 16P392 | 1.5 | 160 | 32 | 2.5 | 1.67 | 1.44 | 350 | 636 | 120 | 170 | 1/4" BSP | 1/2" BSP | 6.5 |
| 16P80 | 1.5 | 160 | 32 | 2.5 | 2.25 | 1.98 | 350 | 636 | 120 | 170 | 1/4" BSP | 1/2" BSP | 8.5 |
| 16P160 | 1.5 | 160 | 32 | 2.5 | 3.58 | 3.24 | 350 | 636 | 140 | 190 | 1/4" BSP | 1/2" BSP | 10.5 |
