รายละเอียดสินค้า
| Type | Square Drive | Torque Range (ft-lbs) | Weight (lbs) | Dimensions (inch) | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| L1 | L2 | H1 | H2 | H3 | H4 | R1 | R2 | ||||
| 1 ATWS | 3/4" | 134-1344 | 5.5 | 5.35 | 7.32 | 1.97 | 3.15 | 3.84 | 5.16 | 1.02 | 3.90 |
| 3 ATWS | 1" | 328-3278 | 11 | 6.69 | 9.61 | 2.68 | 4.13 | 5.04 | 8.11 | 1.34 | 5.35 |
| 5 ATWS | 1½" | 547-5470 | 18 | 8.03 | 11.22 | 3.15 | 5.20 | 5.98 | 9.06 | 1.61 | 5.91 |
| 8 ATWS | 1½" | 783-7831 | 24 | 8.66 | 12.32 | 3.54 | 5.59 | 6.57 | 9.61 | 1.85 | 6.89 |
| 10 ATWS | 1½" | 1127-11272 | 33 | 9.65 | 13.86 | 4.06 | 6.10 | 7.09 | 10.24 | 2.01 | 7.19 |
| 20 ATWS | 2½" | 1937-19370 | 58 | 11.93 | 17.72 | 4.72 | 7.44 | 8.74 | 11.81 | 2.40 | 10.04 |
| 25 ATWS | 2½" | 2523-25226 | 77 | 12.72 | 15.79 | 5.39 | 7.99 | 9.72 | 11.69 | 2.60 | 7.83 |
| 35 ATWS | 2½" | 3535-35354 | 110 | 14.67 | 18.33 | 6.02 | 8.58 | 11.10 | 13.07 | 3.03 | 9.53 |
