รายละเอียดสินค้า
| Type | Torque Range (ft-lbs) | SW (inch) | Drive Cylinder (lbs) | Cassettes (lbs) | Dimensions (inch) | A (inch) | R (inch) | |||
|---|---|---|---|---|---|---|---|---|---|---|
| L | H1 | H2 | W | |||||||
| 2ATWH | 164-1638 | 7/8" - 2-3/16" | 2.0 | 3.3 | 7.32 | 5.20 | 3.74 | 1.26 | 0.39-0.63 | 1.06-1.69 |
| 170-1698 | 2-3/8" | 2.0 | 3.7 | 7.32 | 5.31 | 3.86 | 1.26 | 0.43 | 1.81 | |
| 4ATWH | 378-3783 | 1-5/8" - 2-9/16" | 4.6 | 8.6 | 9.49 | 6.93 | 5.00 | 1.69 | 0.55-0.63 | 1.42-2.09 |
| 417-4170 | 2-3/4" - 3-1/8" | 4.6 | 9.5 | 9.69 | 7.32 | 5.39 | 1.69 | 0.59 | 2.2-2.4 | |
| 8ATWH | 758-7582 | 1-5/8" - 2-15/16" | 8.2 | 13.0 | 11.42 | 8.11 | 6.14 | 2.09 | 0.63-0.87 | 1.81-2.36 |
| 758-7582 | 3-1/8" - 3-11/16" | 8.2 | 13.0 | 11.42 | 8.11 | 6.14 | 2.09 | 0.63-0.87 | 1.81-2.36 | |
| 816-8160 | 3-7/8" - 4-1/4" | 8.2 | 13.9 | 11.69 | 8.46 | 6.50 | 2.09 | 0.67 | 2.95-3.07 | |
| 14ATWH | 1346-13456 | 2" - 4-5/8" | 14.1 | 25.1 | 14.21 | 9.41 | 7.44 | 2.52 | 0.75-1.22 | 2.36-3.43 |
| 30ATWH | 3043-30426 | 4-5/16" - 6-1/8" | 28.7 | 39.7 | 16.54 | 11.93 | 10.71 | 3.35 | 1-1.22 | 3.03-4.53 |
| 3240-32396 | 6-1/2" - 6-7/8" | 28.7 | 45.2 | 16.93 | 12.40 | 11.22 | 3.35 | 1-1.22 | 4.8-5.04 | |
