รายละเอียดสินค้า
| Type | Torque Range (ft-lbs) | Square Drive | Weight (lbs) | Dimensions (inch) | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| L1 | L2 | H1 | H2 | H3 | H4 | R1 | R2 | ||||
| 07IBT | 81-814 | 3/4" | 3 | 4.37 | 5.47 | 1.65 | 2.60 | 2.99 | 4.25 | 0.83 | 2.68 |
| 1IBT | 135-1354 | 3/4" | 6 | 5.71 | 6.85 | 1.97 | 2.83 | 3.78 | 5.16 | 1.02 | 3.35 |
| 3IBT | 332-3325 | 1" | 11 | 7.01 | 9.02 | 2.68 | 3.74 | 5.00 | 6.97 | 1.34 | 4.49 |
| 5IBT | 554-5548 | 1-1/2" | 18 | 8.31 | 10.67 | 3.15 | 4.84 | 5.87 | 7.83 | 1.54 | 5.39 |
| 8IBT | 794-7945 | 1-1/2" | 24 | 8.74 | 11.54 | 3.54 | 5.28 | 6.57 | 8.54 | 1.85 | 6.02 |
| 10IBT | 1143-11435 | 1-1/2" | 33 | 9.69 | 12.52 | 3.94 | 5.59 | 7.17 | 9.13 | 2.01 | 6.06 |
| 20IBT | 1965-19651 | 2-1/2" | 62 | 12.13 | 15.12 | 4.72 | 7.20 | 8.66 | 10.63 | 2.32 | 7.32 |
| 25IBT | 2559-25592 | 2-1/2" | 77 | 12.72 | 15.79 | 5.39 | 7.87 | 9.72 | 11.69 | 2.60 | 7.83 |
| 35IBT | 3586-35867 | 2-1/2" | 104 | 14.69 | 18.33 | 6.02 | 8.50 | 11.10 | 13.07 | 3.03 | 9.49 |
| 50IBT | 5306-53064 | 2-1/2" | 192 | 15.75 | 20.31 | 6.30 | 8.78 | 11.46 | 13.43 | 3.19 | 10.20 |
