รายละเอียดสินค้า
| Type | SW (inch) | Torque Range (ft-lbs) | Drive Cylinder (lbs) | Cassettes (lbs) | Dimensions (inch) | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| L | H1 | H2 | W1 | W2 | A | R | |||||
| 2LOW | 7/8" - 2-3/16" | 170-1696 | 2.20 | 3.52 | 7.69 | 4.96 | 4.03 | 1.26 | 2.01 | 0.39-0.63 | 1.06-1.69 |
| 2-3/8" | 177-1770 | 2.20 | 3.74 | 7.69 | 5.06 | 4.14 | 1.26 | 2.01 | 0.43 | 1.81 | |
| 4LOW | 1-1/4" - 2-9/16" | 431-4314 | 4.40 | 9.68 | 10.15 | 6.97 | 5.35 | 1.65 | 2.60 | 0.55-0.63 | 1.42-2.09 |
| 2-3/4" - 3-1/8" | 476-4775 | 4.40 | 10.12 | 10.35 | 7.37 | 5.74 | 1.65 | 2.60 | 0.59 | 2.2-2.4 | |
| 8LOW | 1-7/16" - 3-11/16" | 808-8068 | 7.26 | 17.60 | 11.96 | 8.16 | 6.66 | 2.09 | 3.27 | 0.63-0.87 | 1.81-2.36 |
| 3-7/8" - 4-1/4" | 867-8664 | 7.26 | 18.48 | 11.96 | 8.51 | 7.01 | 2.09 | 3.27 | 0.67 | 2.95-3.07 | |
| 14LOW | 2" - 4-5/8" | 1364-13644 | 12.10 | 25.52 | 14.25 | 9.42 | 8.04 | 2.52 | 3.90 | 0.75-1.22 | 2.36-3.43 |
| 30LOW | 2-3/8" - 6-1/8" | 3083-30828 | 25.08 | 63.80 | 16.57 | 11.94 | 10.72 | 3.35 | 5.16 | 0.98-1.14 | 3.03-4.53 |
| 6-1/2" - 6-7/8" | 3282-32819 | 25.08 | 66.00 | 17.05 | 12.41 | 11.23 | 3.35 | 5.16 | 1.06-1.42 | 4.8-5.04 | |
